BendPak HD-7PXW 7,000lb 4 Post Lift – Super Tall

HD-7PXW 7,000lb 4 Post Lift – Super Tall by BendPak

Managing vehicle storage or display can be a challenge, especially when you’re dealing with limited floor space or needing to stack taller vehicles safely. Without the right lift, you risk inefficiency, inconvenience, or worse—compromised safety. The HD-7PXW 4-Post Lift transforms your space with its incredible 145.25-inch lifting height, perfect for stacking vehicles or showcasing inventory.

Built to handle up to 7,000 lbs., its heavy-duty construction, electric-hydraulic power system, and 31 multi-position locking points deliver unmatched reliability and safety. Designed for versatility, it accommodates a wide range of vehicles, with premium features like oversized self-lubricating cable rollers and a streamlined single hydraulic cylinder. Whether you’re a dealership, garage owner, or vehicle enthusiast, the HD-7PXW is a towering solution to your toughest challenges.

4 Post Lift HD-7PXW Specification

• Capacity: 7,000 lbs. (3,175 kg)
  • Max Capacity per Axle: 3,500 lbs. (1,588 kg)
• Rise:
  • Min. Runway Height: 5″ (127 mm)
  • Max. Rise: 140.25″ (3,562 mm)
  • Max. Lifting Height: 145.25″ (3,689 mm)
  • Time to Full Rise: 50 seconds
• Overall Dimensions:
  • Width: 110.25″ (2,800 mm)
  • Length (including ramps): 213″ (5,688 mm)
  • Column Height: 158″ (4,013 mm)
• Inside Dimensions:
  • Width Between Columns: 100.25″ (2,546 mm)
  • Drive-Thru Clearance: 86.5″ (2,197 mm)
• Runways:
  • Width: 19″ (483 mm)
  • Length: 182.25″ (4,629 mm)
  • Width Between Runways: 35″ (889 mm) or 41″ (1,041 mm)
  • Runway Centerline: 57″ (1,448 mm) or 63″ (1,600 mm)
  • Outside Edge of Runways: 75.75″ (1,924 mm) or 82″ (2,083 mm)
• Minimum Wheelbase:
  • Rated Capacity: 135″ (3,429 mm)
  • 75% Capacity: 115″ (2,921 mm)
  • 50% Capacity: 95″ (2,413 mm)
  • 25% Capacity: 80″ (2,032 mm)
• Locking:
  • Positions: 31
  • Spacing: Every 4″ (102 mm)
• Power Unit:
  • Motor: 208-230 VAC / 50-60 Hz / 1Ph
  • Noise Level: 45 dB
• Shipping:
  • Weight: 2,254 lbs. (1,022 kg)
  • Dimensions: 192″ x 22″ x 31″ (4,876 mm x 558 mm x 787 mm)

HD-7PXW 7,000lb 4 Post Lift Special Features

• 7,000-lb. maximum lifting capacity
• Super tall rise delivers 12-feet of lifting height
• Electric / hydraulic power system
• Single hydraulic cylinder mounted underneath runway
• Internal anti-sway slider blocks in each column
• Oversized self-lubricating cable rollers
• Features heavy-duty 3/8” aircraft cable
• Rugged 1.25” roller axles
• Multi-position safety locks in each column
• Adjustable lock ladders
• Ramps feature non-skid surface
• Push-button pneumatic safety release
• Warranty
  • 5 Year – Lift Structure
  • 2 year – Hydraulic Unit & Power Unit
  • 1 Year – Electrical and Operating Components
  • Reasonable labor costs covered for first 12 months

BendPak HD-7PXW Documentation

  BendPak HD-7PXW Installation and Operations Manual

  BendPak HD-7PXW Product Brochure
